brake drum/disc lathe machine-C9350 |
| |
|
| |
This machine tool suits the needs of various cylinder cover for every
engine. It adopts the air-floating work table. When equipped with all
sorts of tools, it can manufacture the gas valve seats hole for cylinder
cover with various angles. When equipped with boring-drilling tools,
it can bore drills. It is widely used to ream the pipe seats holes for
gas valves.
|
Spindle Travel 6-7/8" / 175mm
Spindle Speed 70，80， 118 RPM
Spindle Feed Speed Min 0.002 Inch Per Revolution / 0.05 Mm/Rev
Max 0.02 Inch Per Revolution / 0.5 Mn/Rev
Cross Feed Speed Min 0.002 Inch Per Revolution / 0.05 Mn/Rev
Max 0.01 Inch Per Revolution / 0.25 Mn/Rev
Handwheel Graduations 0.002" / 0.05mm
Rotor Diameter 7" / 180mm - 15" / 381mm
Rotor Thickness 1-7/8" / 48mm
Drum Diameter 6" / 152mm - 28: / 711mm
Drum Depth 6-7/8" / 175mm
Motor 1PH 220VAC 50/60Hz 3PH 380VAC 50/60Hz
Gross Weight 200KG
Dimension 970X920X1140mm
