Features
·Provide variable speed and rotation torque during brake machining is a characteristic of this equipment.
· The spindle rotation speed swivels within a certain range,this can eliminate the mechanical resonance and enable the machined surface to be smooth.
·The 1.5-hp powerful motor can machine brakes for4-wheel drive automobiles,1t trucks and even medium duty truck's rear wheels easily.
·The micro-round cutter blade can undergo knock,it can be rotated by an angle after it has been worn to elongate its service life.
·The brake lathe can be rotated180° to machine the automobile at its another side. lt is very convenientin use because it is unnecessary to remove the bolts and move the arbor.
·Theunique twin-arbor design makes it be adjusted conveniently and the machining with high efficiency.
· Semiautomatic operation system.
·Automatic safety and shutdown system.
·Fast connection system.
·Intermittent feed mechanism makes the machined surface conform to be the demands of use.

Specifications
Maximum Rotor Turning Diameter:14.1 inches(360mm)
Maximum Rotor Thickness:2.00 inches(51mm)
Maximum RotorFriction Surface Area:3.00 inches(76mm)
Feed Distance:4.3 inches (110mm)
Spindle Revolutions:Variable Speed 30-120RPM
Motor Power:1.5HP(1.1kw)@3450rpm
Dimensions:31-in.x18.x15-in.
Net Weight:Approximately90lbs.(41kg)(Without trolley)
Electric Power:AC220 volts 50/60Hz 15A
